        화공기기

        당사는 대형 화공기기(최대: 12,000Dia x 100,000LG/중량 약1,000톤)들을 제작하고 있으며, 완성된 제품은 주로 율촌공장 인근에 위치한 율촌부두를 통하여 출하되고 있습니다. 반면, 육상운반 크기의 한계를 고려하여, 공장에서 반제품으로 제작한 후 설치 현장에서 최종 완제품으로의 제작을 요구한 프로젝트 (공장+현장 제작)도 수행해 왔습니다.

        그 동안, 인도의 Reliance의 Jamnagar Export Refinery Project, Essar의 Oil Refinery Expansion Project 및 한화케미칼의 Orange Project 등을 수행해 오면서 수 많은 화공기기(Pressure Vessel, Fired Heater, Heater 및 Heat Exchanger)들을 제작해 왔습니다.

        다른 한편, 공장+현장제작이 결합된 주요 수행 화공기기들은 사우디아라비아의 마덴(Ma’aden) Phosphoric Acid Project 및 우즈베키스탄의 "UZ-KOR GAS CHEMICAL" Ethylene Plant 등의 Pressure Vessel(FSA Scrubber, Vacuum Cooler 및 Column 등)이 있습니다.

        이러한 공장과 현장제작이 결합된 화공기기 제작분야에 대해서도 당사가 세계시장에서 인정을 받고 있는 분야이므로 점차 사업비중을 늘려갈 예정입니다.

        발전기기

        발전플랜트와 화공플랜트에서 생산되는 제품은 서로 다르지만, 플랜트를 구성하고 있는 많은 단위기기들은 동일한 기능 및 목적으로 사용되고 있습니다.

        당사는 화공플랜트에도 동일한 기능 및 목적으로 설치되는 Pressure Vessel, Feedwater Heater & Heat Exchanger(Shell & Tube Type)뿐 아니라 Steam Drum, Deaerator 등도 고객의 요구에 맞게 설계 및 제작할 수 있는 능력을 갖추고 있으며, 수행 경험도 보유하고 있습니다.

        Pressure Vessel & Equipment

        NO PROJECT NAME OWNER DESCRIPTION Q'TY
        (UNIT)        		 W'T
        (M/T)        		 DIMENSION
        (IDxTHKxLG, mm)        		 MAT'L D.P kg/cm²
        (INT./EXT)        		 D.T ℃
        (INT./EXT)        		 PERIOD REMARKS
        1 RDMP RU-V PJT PT PERTAMINA UOP Vessels 17 223 1,100/2,700 x 10~45 x 7,250 SA516-70 +S3 52.5/FV 425 JUL.,22~
        DEC.22
        Spray Tower 1 377 9,750/5,650 x 26/12 x 58,845 SA240-304/SA240-304L DUAL 0.127 425 SEP.22~
        MAR.23
        Column & Vessels. 13 566 2,850 x 60 x 18,950 / 4,500 x 20 x 20,000 SA516-70N + HIC / SA516-60N + S5 + HIC 17.4/FV 150 AUG.22~
        MAR.23
        1 17 1,900 x 12+3 x 8,600 SA516-60N + S5 + 410S 3.8/FV 286
        2 18 1,650 x 12+3 x 4,050 SA516-70N +SS304L 3.7/FV 109
        13 410 2,800/4,600x 13~31 x 14,250 SA516-70N 4/FV 225 AUG.22~
        MAR.23
        Small Vessels 8 234 4,300 x 35 x 14,600 SA516-60N+S5 (HIC) 41.4/FV 230/150 SEP.22~
        MAR.23
        2 55 3,350 x 12 x 8,380 SA240-304L FULL LIDUID 100 AUG.22~
        MAR.23
        14 115 2,400 x 16 x 6,200 SA516-70N+S5 27.7/FV 283/150 SEP.22~
        MAR.23
        2 CARIFLEX SPRING PROJECT Reactor 1 25 4,500 x 23 x 8,600 SA516-70 10 / F.V 200/200 APR.22~
        MAR.23
        Vessels 26 34 3,700 x 12 x 17,950 SA240-304L 3.5 / F.V 150/150
        18 220 8,000 x 20 x 33,460 SA516-70 6 / F.V 75/75
        4 LINE PROJECT PT. LOTTER CHEMICAL INDONESIA C3 Splitte 2 3,212 7,600 x 48/42 x 68,800 SA516-70N+S5 18.5 -46 / 70 FEB.'22~
        JUN.'23
        Pyrolysis Fractionator 1 939 10,500 x 32 x 38,000 SA516-70N 3.5/H.V 16 / 350
        Water Quench Tower 1 821 11,500 x 30/26 x 30,100 SA516-70N 3.5/H.V 16 / 370
        5 HSC HPC PROJECT HANWHA CHENICAL Vessels. 7 40 4,650 x 6 x 5,700 SA516-70 +TEFLON LINING 1.1 90 JAN.'22~
        JUN.'23
        1 11 3,000 x 13 x 4,300 SA516-70 ALLOY 625 CLAD 3.5 150
        7 180 4,600 x 6 x 7,000 SA516-70 3.5 150
        6 PKN OLEFINS EXPANSION PROJECT(EOSE) PKN ORLEN Effective Distillation Column 7 420 4,100 x 29/14 x 83,700 SA516-70 3.5/H.V 200 DEC.'21~
        OCT.'22        		 ASME VIII DIV.1
        7 NCC #2 A410 Tower Size-Up Project YNCC Demethanizer Prefractionator 1 174 3,000 x 29/14 x 83,700 SA537-CL2+S5 38 65 DEC.'21~
        DEC.'22        		 ASME VIII DIV.1
        8 PKN OLEFINS EXPANSION PROJECT(EOSE) PKN ORLEN C3 Splitte 1 922 6,600 x 48/42 x 112,300 SA516-70N+S5 18.5 -46 / 70 AUG.'21~
        APR.'23        		 ASME VIII DIV.1
        Pyrolysis Fractionator 1 330 8,900 x 29/26 x 37,100 SA516-70N+S5 3.5/H.V -29 / 360
        Water Quench Tower 1 418 10,200 x 33/25 x 38,200 SA516-70N+S5 3.5/H.V -29 / 360
        9 HSVC OL1 PROJECT (PV-I) HYOSUNG VINA C3 Splitte Reciever 1 406 8,200 x 52 x 23,500 A516-70N+S5 16 -0.2416667 SEP.'20~
        JAN.'20        		 ASME VIII DIV.1
        COLUMN & DRUM 21 831 8,000 x 30 x 12,500 A516-70N+S5 5.0/HV 150 / 100
        10 HSVC OL1 PROJECT (PV-II) HYOSUNG VINA DRUM 22 72 3,200 x 10 x 3,800 A240-304
        SA516-70        		 0.65 535 NOV.'20~
        JAN.'20        		 ASME VIII DIV.1
        11 RDMP RU-V PJT PT PERTAMINA HOPPER 4 1,812 8,700 x47 x 43,500 SA516-70N 5.0/F.V 425/425 FEB.'21~
        DEC.'19        		 ASME VIII DIV.1
        HP Separator Drum 1 280 6,500 x 56 x 19,400 SA516-60N+HIC 17.4/F.V 85/150
        Catalyst cooler Aux Steam Drum 1 473 6,250 x 106 x 20,000 SA516-70N 43.0/F.V 278/278
        RFCC Flare KO Drum 1 179 6,500 x 25 x 26,000 SA516-60N+HIC 3.5/F.V 230/230
        DRUM 5 350 5,600 x 25 x 17,800 SA516-70N
        SA516-60N+HIC        		 5.0/F.V 128/150
        12 NCC2 PROJECT YNCC Quench Oil Tower 1 370 8,100 x 25 x 49,960 SA516-70N 3.5 /HV 415/415 APR.'19~
        MAY.'20        		 KGS + ASME VIII
        Ethylene Splitter 1 586 3,700 x 62 x 96,560 SA516-70N 21.0 / - 65/-
        Propylene Splitter 1 794 4,600 x 55 x 106,350 SA516-70N 23.0 / - 100/-
        COLUMN 4 300 3,200 x 23 x 47,670 SA516-70N 8.8 / - 100/-
        13 UAE ADNOC REFINING CFP, MDA120&130 ADNOC MDEA Regenerator, ETC 17 749 4,000 x 16+3 x 35,550 SA516-65N + 316L S.S CLAD 6.2 / F.V 175 / 175 SEP. '18~OCT.'19 ASME VIII DIV.1
        ADNOC REFINING CFP PROJECT COLUMN 8 122 1,500 x 20 x 36,000 SA516-65N 12.8 / F.V 210
        Strippe 4 86 2,200 x 14.5 x 25,100 SA516-65N + 316L S.S CLAD 10.8 / F.V 186/150
        14 V3 PROJECT HANWHA CHENICAL COLUMN 7 196 2,400 x 18 x 39,550 SA516-70 4.0 / H.V 160 / 160 JUL.'18~
        MAY.'19        		 KGS + ASME VIII
        15 HEC MELAKA REFINERY DIESEL EURO 5 PJT MALAYSIAN REFINING COMPANY VESSEL & DRUM 25 216 4205 x 25 x 11900 SA516-60N(HIC)
        (NACE MR0103)        		 10 / F.V 100 / 16.8 MAR.'18~
        MAY.'19        		 ASME VIII + DOSH
        16 THE PROJECT HANWHA CHENICAL COLUMN 2 69 2,300 x 16 x 35,615 SA516-70 3.5 / H.V 250 / 250 OCT.'17~
        AUG.'18        		 KGS + ASME VIII
        17 S-OIL RESIDUE UPGRADING COMPLEX PROJECT S-OIL DRUM 81 1,625 5,000 x 45 x 16,740 SA516-70N 3.5 / H.V 340 / 150 MAY.'16~
        APR.'17        		 KGS + ASME VIII
        HOPPER 6 1,552 8,900 x 32/55 x 54,350 SA516-70N 5 / F.V 425 / 425 KGS + ASME VIII
        18 S-OIL SUPER PROJECT PKG-1(RFCC REACTOR PACKAGE) S-OIL REACTOR 1 515.5 7,800/4,600 x 38 x 30,570 SA516-70N 3.5 565 / 350 MAY.'15~
        AUG.'16        		 KGS + ASME VIII
        19 IP PROJECT LOTTE CHEMICAL PRESSURE VESSEL 53 594 4,200 x 17 x 12,000 SA106-B, SA240-304L, SA516-70 12.3 / F.V 130 / 130 APR.'15~
        FEB.'16        		 ASME VIII
        20 IP BEP & FEED PROJECT LOTTE CHEMICAL COLUMN 7 1,023 3,800 x 23 x 63,150 SA516-70 5.0 / F.V 130 APR.'15~
        DEC.'15        		 KGS + ASME VIII
        EVAPORATOR FLASH CHAMBER, ETC. 39 3,619 8,000 X 25 X 13,750 SA516-70 1.4 / F.V 90
        21 IP BEP & FEED PROJECT LOTTE CHEMICAL CO. COLUMN 7 1,023 3,800 x 23 x 63,150 SA516-70 5.0 / F.V 130 APR.'15~
        DEC.'15        		 KGS + ASME VIII
        22 Ma'aden, PAP(PHOSPHORIC ACID PROJECT) Ma'aden MINING COMPANY VACUUM COOLER 3 510 12,000 X 22 X 15,300 SA516-70 1.4 / F.V 90 AUG.'14~
        MAR.'16        		 SHOP FAB.+ FIELD ASSEMBLY
        EVAPORATOR FLASH ASSEMBLY CHAMBER, ETC. 39 3,619 8,000 X 25 X 13,750 SA516-70 1.4 / F.V 90
        23 MULTI-EFFECTION DISTILLATION PROJECT YNCC COLUMN 1 149 3,800 x 24 x 60,050 SA516-60 3.5 / F.V 160 / 150 JUN.'14~
        FEB.'15        		 KGS + ASME VIII
        24 3PZ PROJECT HONAM-MITSUI CHEMICAL INC. WASTE STEAM SETTLER & STRIPPER 3 6 1,100 X 5 X 2,100 DUPLEX(SA240-S31260) 5.1 95 DEC.'11~
        JUN.'12        		 ASME VIII,DIV.1
        HX CONDENSATE RECEIVER & ETC. 18 136 1,100 X 6 X 1,900 DUPLEX(SA240-S31260) 1.84 / F.V 60 / 60
        REACTOR 1 18 2,590 X (24+3)/14 X 2,800 CLAD(A516-60N+316L) 7.14 / F.V -40 & 170
        25 ORANGE PROJECT/PRESSURE VESSEL-1 HANWHA CHEMICAL CORP. STC SUMP DRUM 3 274 7,600 X 16~20 X 13,300 SA516-70 3.5 120 NOV.'11~
        AUG.'12        		 ASME VIII,DIV.1
        MG-SI PRESSURE FEED HOPPER 32 1,285 7,200 X 31 X 20,200 SA516-70 3.6 / F.V 160
        26 ESSAR OIL REFINERY EXPANSION PROJECT ESSAR OIL LIMITED STRIPPER 1 272.2 3,900 x (20+3)/25 x 48,960 SA516 Gr.70N + 316L 11 / F.V 320 NOV.'09 ~
        SEP.'10        		 ASME VIII, DIV.1
        RECYCLE GAS SCRUBBER 1 258.5 3,700 x 121 x 11,900 SA516 Gr.70N 96.2 / F.V 120 / 46 OCT.'09 ~
        AUG.'10
        PRODUCT FRACTIONATOR 1 175.3 5,700 x (14+3) / (16+3) x 51,150 SA516 Gr.70N + 410 3.5 / F.V 385 / 340 OCT.'09 ~
        AUG.'10
        RICH AMINE FLASH DRUM & ETC. 6 253.6 4,500 x 25 x 20,400 SA516 Gr.70N 12 / F.V 75 DEC.'09 ~
        JUL.'10
        FUEL GAS SCRUBBER 10 489 2,900 x 18/22 x 37,800 SA516 Gr.60 11 / F.V 90 OCT.'09 ~
        AUG.'10
        27 JAMNAGAR EXPORT REFINERY RELIANCE MAIN FLARE KNOCKOUT DRUM & ETC. 3 461 6,900 x 30 x 30,500 SA516-70 5.5 / 0.175 343 / 150 FEB.'08 ~
        OCT.'08        		 ASME VIII, DIV.1
        LP FLARE KNOCKOUT DRUM 2 310.2 5,500 x 36 x 27,750 SA516-70 3.5 / 0.175 343 / 150 JUN.'08 ~
        FEB.'09        		 ASME VIII, DIV.1
        CAUSTIC PREWASHER 2 265.5 6,100 x 70 x 11,000 SA516-70N 25 / 0.18 70 / 150 AUG.'06 ~
        APR.'07        		 ASME VIII, DIV.1
        29 JAMNAGAR EXPORT REFINERY RELIANCE MAIN COLUMN RECEIVER 2 458 8,400 x 20 x 25,400 SA516-70N 3.5 / 0.18 150 / 150 FEB.'06 ~
        OCT.'06        		 ASME VIII, DIV.1
        MAIN COLUMN REFLUX DRUM 1 234.5 8,400 x 20/50 x 21,200 SA516-70 3.5 / 0.18 150 / 150 FEB.'06 ~
        OCT.'06        		 ASME VIII, DIV.1
        KNOCKOUT DRUM & ETC. 24 1807 7,000 x 25 x 19,200 SA516-70 5.3 / H.V 150 FEB.'08 ~
        OCT.'08        		 ASME VIII, DIV.1
        BLOWDOWN SETTLING DRUM & ETC. 308 6,268.10 3,050 x 15 x 15255 SA516-70N 5.1 / F.V 180 FEB.'06 ~
        FEB.'09        		 ASME VIII, DIV.1
        30 RFCCU RENOVATION PROJECT CHEVRON PRODUCTS CO. (USA) FCCU REACTOR 1 102.7 5,182x25x25,451 SA387-11 CL.1 12.0 / F.V 343 JAN.'02 ~
        JAN.'03
        31 EXXONMOBIL LOW SULPHUR MOGAS PROJECT EXXON MOBIL (USA) HCN MAIN REACTOR 2 176.4 4,267x63.5x12,065 SA387-11 CL.2 + SA240 TP304L 43.1 / F.V 300 OCT.'01 ~
        OCT.'02        		 U2 STAMP
        STAGE 1. SCANFINING REACTOR 1 266.3 6,400x82.5x7,163 SA387-11 CL.2 + SA240 TP304L 38.5 / F.V 300 OCT.'01 ~
        OCT.'02        		 U2 STAMP
        STAGE 2. SCANFINING REACTOR 1 265 6,400x82.5x7,163 SA387-11 CL.2 38.5 / F.V 300 OCT.'01 ~
        OCT.'02        		 U2 STAMP
        1ST STAGE SCANFINING REACTOR 1 139 4,876x62x6,985 SA387-11 CL.2 + SA240 TP304L 37.3 / F.V 343 OCT.'01 ~
        OCT.'02        		 U2 STAMP
        2ND STAGE SCANFINING REACTOR 1 139 4,876x62x6,985 SA387-11 CL.2 37.3 / F.V 343 OCT.'01 ~
        OCT.'02        		 U2 STAMP
        32 RAS LAFFAN ONSHORE PROJECT RAS LAFFAN LNG CO., LTD (II) (QATAR) PRODUCT GAS KNOCKOUT DRUM 1 315 5,250x170x8,300 SA266-4 63.6 / F.V 420 AUG.'01 ~
        JUN.'02        		 U STAMP
        FEED KNOCKOUT DRUM 1 341 5,600x146x11,100 SA516-70 50.7 / F.V 300 AUG.'01 ~
        MAY.'02        		 U STAMP
        LP MP SUCTION DRUM 1 198 9,050x35x11,450 SA240 TP304L 7.2 / F.V 250 AUG.'01 ~
        JUN.'02        		 U2 STAMP
        33 RAS LAFFAN ONSHORE PROJECT RAS LAFFAN LNG CO., LTD (QATAR) TEG CONTRACTOR INLET SEPARATOR 1 170 3,600 x (180+3) x 5,440 SA226-4 95.4 / F.V 260 AUG.'01 ~
        JUN.'02        		 U2 STAMP
        MOLECULAR SIEVES 1 150 4,200 x 116 x 7,300 SA516-65 55.2 / F.V 280 AUG.'01 ~
        MAY.'02        		 U2 STAMP
        MERCURY REMOVAL VESSEL 1 140 4,900 x 137 x 3,500 SA516-65 55.2 / F.V 280 AUG.'01 ~
        JUN.'02        		 U2 STAMP
        34 JAMNAGAR REFINERY EXP. PROJECT RELIANCE JAMNAGAR REF.(INDIA) GUARD BED REACTOR 2 301 5,492 x (157+3) x 7,000 SA336-F22 V +309L/347S.S WELD OVERLAY 80.0 / F.V 350 JUL.'01 ~
        JUL '02        		 ASME VIII, DIV.1
        35 S-OIL NEW HYVAHL COMPLEX PROJECT S-OIL (KOREA) HP AMINE ABSORBER 1 280.5 2,640 x 171 x 18,550 SA-266-CL.4 150 / F.V 310 APR.'01 ~
        FEB.'02        		 ASME VIII, DIV.1
        HP GAS WASHING DRUM 1 184.2 2,500 x 160 x 13,400 SA-266-CL.4 150 / F.V 310 APR.'01 ~
        MAR.'02
        HIGH & LOW TEMP. CONVERTER 5 214 3,800 x 49/44 x 3,790 SA387-11 CL.2 35.8 / F.V 252 APR.'01 ~
        MAR.'02
        36 LYONDELL PO-11 PROJECT LYONDELL CHEMICAL NETHERLAND, LTD. (NETHERLANDS) LIGHTS COLUMN 1 295.7 8,100 x 27 x 25,800 A516-60 8.2 / F.V 250 OCT.'00 ~
        AUG.'01        		 CE STAMP
        STYRENE COLUMN 1 207.1 7,800/7,530 x 26 x 19,945 A516-60 7.5 / F.V 250 OCT.'00 ~
        AUG.'01        		 CE STAMP
        BENZENE COLUMN 1 309 5,400 x 30 x 30,900 A516-60 13.7 / F.V 283 OCT.'00 ~
        AUG.'01        		 CE STAMP
        37 HPC 3PP PROJECT HONAM PETROCHEMICAL (KOREA) LOOP REACTOR 1 126.8 690 x 14 x 45,500 SA516-70 10.4 / F.V 250 / 110 JUN.'00 ~ MAY.'01 U STAMP
        38 GHANA RFCC PROJECT TEMA OIL REFINERY (GHANA) REACTOR 1 131 (4,500/2,400) x (27/24) x 26,200 SA387-11 CL.1 15.6 / F.V 280 / 150 DEC.'99 ~
        MAR.'01
        39 SINCOR DOWNSTREAM PROJECT SINCOR CA. (VENEZUELA) COLD HP SEPARATOR DRUM 2 405 3,400 x 127 x 14,050 SA516-70 105 / F.V 280 / 152 DEC.'99~
        FEB.'00        		 U STAMP
        HP AMINE ABSORBER 2 184.7 3,000 x 60 x 19,000 SA516-70 50.2 / F.V 283 DEC.'99~
        FEB.'00        		 U STAMP
        HP AMINE ABSORBER 1 223.2 3,100 x 112 x 19,750 SA516-70 93.8 / F.V 300 DEC.'99~
        FEB.'00        		 U STAMP
        COLD HP SEPARATOR 2 356.5 4,000 x 81 x 11,200 SA516-70 51.6 / F.V 300 DEC.'99~
        FEB.'00        		 U STAMP
        40 EXXON BAYTOWN DELAYED COKER PJT EXXON USA (USA) MAIN COKER FRACTIONATOR 1 131.1 4724 x (17+3/20+3) x 34138 A516-70/A240 TP410S 6.2 / F.V 210 / 110 SEP.'99 ~
        JUL.'00        		 ASME VIII, DIV.1
        41 NODCO REFINERY EXPANSION PROJECT NATIONAL OIL DISTRIBUTION CO.(QATAR) MAIN COLUMN 1 155 4,700 x (31+3/34+3) x 3,9350 A387-11 CL.2/ A240 TP410S 11.2 / F.V 200 / 100 JUL.'99 ~
        JUN.'00        		 U STAMP
        42 CPC RFCC PROJECT CHINESE PETROLEUM CORP. (TAIWAN) FRACTIONATOR 1 307.3 6,700 x (23/34+3) x 40,850 SA387-11 CL.2 +TP410SS CLAD 8.1 / F.V 320 ASME VIII, DIV.1
        TERTIARY CYCLONE VESSEL 1 227.1 9,150 x 29 x 10,563 A516-70 / SA240 TP304H 8.5 / F.V 251
        43 EXXON BAYTOWN DELAYED COKER PJT EXXON USA MAIN COKER FRACTIONATOR 1 131.1 4724 x (17+3/20+3) x 34138 A516-70/A240 TP410S 6.2 / F.V 210 / 110 SEP.'99 ~
        JUL.'00        		 ASME VIII, DIV.1
        44 NODCO REFINERY EXPANSION PROJECT NATIONAL OIL DISTRIBUTION CO.(QATAR) MAIN COLUMN 1 155 4,700 x (31+3/34+3) x 3,9350 A387-11 CL.2/A240 TP410S 11.2 / F.V 200 / 100 JUL.'99 ~ JUN.'00 U STAMP
        45 CPC RFCC PROJECT CHINESE PETROLEUM CORP. (TAIWAN) FCCU REACTOR 1 335.0
        (474.0)        		 7,574 x 30/32 x 37,956 SA516-70 15.3 / F.V 212 / 110 FEB.'99 ~
        OCT.'00        		 ASME VIII, DIV.1
        47 CPC RFCC PROJECT CHINESE PETROLEUM CORP. (TAIWAN) WATER DISENGAGING DRUM 1 189.9 3,658/7,315 x (12+3/26+3) x 57,920 A516-60/A240 TP316L 5.6 / F.V 212 / 110 FEB.'99 ~
        OCT.'00        		 ASME VIII, DIV.1
        46 AMNAGAR REFINERY PROJECT RELIANCE PETROLEUM LTD (INDIA) VACUUM TOWER 1 445.0 5,900/11,000 x 19/24/24+3 x 25,350 A516-70 + A240 TP410S 8.5 / F.V 300 AUG.'97 ~
        MAR.'98
        CRUDE TOWER 1 840.0 9,600 x (29+3/54+3) x 62,700 A516-70 + A240 TP410S 8.3 / F.V 250
        FCC REACTOR 1 960.0 10,200 x (55+3) x 40,300 A387-22 + 410S 15.2 / F.V 250
        47 COASTAL ARUBA CAPACITY EXPANSION PROJECT COASTAL ARUBA REFINING CO. (ARUBA) COKE DRUMS 2 275.0 8,382 x (21+3/39+3) x 25,908 A387-11 CL.1/ SA240 TP410S 7.5 / F.V 200 / 100 AUG.'98 ~
        AUG.'99
        COKE FRACTIONATOR 1 68.0 3,962 x (13+3) x 23,926 A240B/SA240 TP410S 7.5 / F.V 200 / 100
        48 SINCOR DOWNSTREAM PROJECT SINCOR C.A. (VENEZUELA) CRUDE COLUMN 1 301 4,600/7,000 x (13+3)/ (17+3) x 4,6650 A516-70/A240 TP317L 7.7 / F.V 208 / 106 DEC.'98 ~
        FEB.'00        		 U STAMP
        VACUUM COLUMN 1 764 8,600/13,000 x (32+3)/ (37+3) x 42,910 A516-70/A240 TP317L 10.1 / F.V 208 / 150 DEC.'98 ~
        FEB.'00        		 U STAMP
        49 RF - II & OL - II PROJECT FORMOSA PETROCHEMICAL CORP. (TAIWAN) MAIN COLUMN 1 420.0 8,100 x (19+3/45+3) x 44,200 SA387-11-CL.1+ SA240 TP410S 4.8 / F.V 209 / 110 APR.'98 ~
        NOV.'98
        ATMOSPHERIC TOWER 1 591.1 8,000 x (28+3/40+3) x 53,950 A516-60 + SA240 TP410S 8.1 / F.V 209 / 110

        Heat Exchanger

        NO PROJECT NAME OWNER ENG. CONSULTANT OR CONTRACTOR DESCRIPTION Q'TY
        (UNIT)        		 TOTAL W'T
        (TON)        		 SIZE TYPE MATERIAL LOCATION PERIOD REMARK
        SHELL
        ID        		 LENGTH SHELL TUBE
        1 USTYURT GAS
        CHEMICAL COMPLEX
        PROJECT        		 JV "UZ-KOR GAS
        CHEMICAL LLC"        		 HYUNDAI
        ENGINEERING        		 CONDENSATE
        PREHEATER        		 1 6.3 910 6,217 SADDLE SA516-70N SA213-
        TP304L        		 AKCHALAK,
        UZBEKISTAN        		 FEB.'13~

        DEC.'13        		 ASME VIII
        DIV.1
        LP STEAM
        CONDENSER        		 1 12.6 1,120 5,840
        ETHYNE
        VAPORIZER        		 1 10.1 1,560 5,856
        PROPYLENE
        VAPORIZER        		 1 2.0 920 3,298
        LP CONDENSATE
        DRUM        		 1 13.4 700 6,588
        2 PARDIS 3rd UREA
        & AMMONIA PJT /
        HIGH PRESSURE
        HEAT EXCHANGER        		 P.P.C PARDIS
        PETROCHEMICAL
        CO.        		 AMMONIA CONVERTER/
        EFF. EXCHANGER        		 1 131.5 1,350 24,450 SADDLE SA387-11
        CL.2        		 SA213-T11 TEHRAN,
        IRAN        		 JUN.'12~
        SEP.'13        		 ASME VIII
        DIV.1
        AMMONIA CONVERTER/
        EFF. S/G        		 1 81.5 1,200 9,062 LUG SA336-22
        CL.3 +308L        		 SA213-
        TP321        		 ASME VIII
        DIV.1
        AMMONIA CONVERTER/
        EFF. S/G        		 1 115.2 1,200 7,899 LUG SA387-11
        CL.2        		 SA213-T11 ASME VIII
        DIV.2
        AMMONIA UNITIZED
        CHILLER        		 1 307.5 5,000 25,673 SADDLE SA516-70 SA179 &
        SA334-6        		 ASME VIII
        DIV.1
        3 IPC EVA PROJECT IPC
        (International
        Polymers Company)        		 GS E & C
        CORP.        		 LIGHT ENDS COLUMN
        CONDENSER        		 1 1.4 380 4,000 BEM SA240-304L SA213-
        TP304L        		 JUBAIL,
        SAUDI
        ARABIA        		 JUL.'11~
        MAY,'12
        PRODUCT COLUMN
        CONDENSER        		 1 2.0 520 3,000 BEM SA240-304L SA213-
        TP304L
        VAPOR PRODUCT
        HEATER        		 1 1.1 307.1 1,830 AEU SA333-1 SA334-1
        PROPYLENE DESUPER
        HEATER        		 1 1.3 303.3 3,050 AEU SA333-1 SA334-1
        PROPYLENE
        CONDENSER        		 1 3.0 450 4,880 AEU SA516-60(N) SA334-1
        ETHYENE PRODUCT
        HEATER, ETC        		 15 41.0 247.7 1,700 AEU SA333-1 SA334-1
        4 HEAT EXCHANGERS
        ASS'Y PROJEC        		 KUMHO
        PETROCHEMICAL
        CO., LTD        		 KUMHO
        PETROCHEMICAL
        CO., LTD        		 RECYCLE BD PARTIAL
        CONDENSER        		 1 2.6 450/750 3,000 AKL SA516-
        70+S5        		 S334-1 YEOSU,
        KOREA        		 JUL.'11~
        OCT.'11
        RECYCLE BD PARTIAL
        CONDENSER        		 1 4.6 650/950 3,000 AKL SA516-
        70+S5        		 S334-1
        REACTOR OFF-GAS
        BRINE COOLER        		 1 1.7 460 3,200 AKL SA240-
        TP304L        		 SA213-
        TP304L
        5 ESSAR OIL REFINERY
        EXPANSION PROJECT        		 ESSAR OIL LIMITED TOYO ENG.
        (INDIA)        		 REGENERANT VAPORIZER 8 48 690 7,420 BAYONET A516-70 A179 VADINAR,
        INDIA        		 DEC.'09 ~
        MAY.'10        		 ASME VIII
        TEMA
        POLISHING REACTOR TEMA
        FEED / EFFLUENT
        EXCHANGER        		 1 168 2,350 14,660 AHL JUL.'10 ~
        FEB.'11
        6 JAMNAGAR EXPORT
        REFINERY        		 RELIANCE BECHTEL
        (UK)        		 REACTOR FEED
        HEATER        		 1 4.5 600 6,096 BEU CS CS JAMNAGAR,
        INDIA        		 NOV.'06 ~
        AUG.'07
        DEISOHEXANIZER &
        STABILIZER REBOILER        		 3 24.9 775 6,096 BHU CS CS JAMNAGAR,
        INDIA        		 NOV.'06 ~
        AUG.'07
        REACTOR EFFLUENT
        TRIM COOLER        		 1 14 1,000 6,096 AJS CS CS JAMNAGAR,
        INDIA        		 NOV.'06 ~
        AUG.'07
        MAIN COLUMN BOTTOMS
        STEAM GENERATORS        		 3 199.2 1,600 6,096 AKT KCD SS410 JAMNAGAR,
        INDIA        		 NOV.'06 ~
        AUG.'07
        STRIPPER FEED
        EXCHANGER        		 1 2.9 580 4.277 AEU KCS KCS JAMNAGAR,
        INDIA        		 NOV.'06 ~
        AUG.'07
        STRIPPER REBOILER
        NO.1 & 2        		 2 19.3 760 6,096 AHU KCS KCS JAMNAGAR,
        INDIA        		 NOV.'06 ~
        AUG.'07
        DEBUTANIZER FEED
        EXCHANGER        		 1 5.3 600 6,096 AES KCS KCS JAMNAGAR,
        INDIA        		 NOV.'06 ~
        AUG.'07
        SPENT CAUSTIC
        COOLER        		 1 0.8 254.5 2,134 BGU 316SS 316SS JAMNAGAR,
        INDIA        		 NOV.'06 ~
        AUG.'07
        REGENERATOR
        PUMPAROUND
        WATER COOLER        		 1 0.8 303.2 3,048 AES 317SS 317SS JAMNAGAR,
        INDIA        		 NOV.'06 ~
        AUG.'07
        7 JAMNAGAR EXPORT
        REFINERY        		 RELIANCE BECHTEL
        (UK)        		 CRUDE / INTERMEDIATE
        CR EXCHANGER-I        		 1 15.8 1,025 6,096 AES SA516-60N SA179 JAMNAGAR,
        INDIA        		 AUG.'06 ~
        JUL.'07
        CRUDE / LGO & RCO
        EXCHANGER-I        		 2 34 1,150 6,096 AES SA516-60N SA179 JAMNAGAR,
        INDIA        		 AUG.'06 ~
        JUL.'07
        CRUDE / BOTTOM CR
        EXCHANGER        		 1 35.4 1,425 6,096 AES SA516-60N SA179 JAMNAGAR,
        INDIA        		 AUG.'06 ~
        JUL.'07
        STAB. NAPHTHA PDT
        TRIM COOLER        		 2 13,2 650 6,096 AES SA516-60N SA179 JAMNAGAR,
        INDIA        		 AUG.'06 ~
        JUL.'07
        DESALTER WATER/
        BRINE EXCHANGER        		 2 11.6 640 6,096 AES SA516-60N SA179 JAMNAGAR,
        INDIA        		 AUG.'06 ~
        JUL.'07
        BRINE COOLER 1 7.41 725 6,096 AES SA516-60N SA179 JAMNAGAR,
        INDIA        		 AUG.'06 ~
        JUL.'07
        UNPOLISHED CONDENSATE
        TRIM COOLER        		 2 6.6 650 4,500 AES SA516-
        60N+304L        		 SA213-304L JAMNAGAR,
        INDIA        		 AUG.'06 ~
        JUL.'07
        STEAM VENT
        CONDENSER        		 1 2.4 584 1,829 BEU CS CS JAMNAGAR,
        INDIA        		 AUG.'06 ~
        JUL.'07
        DEMIN WATER
        PREHEATER        		 2 13,4 812 6,096 BEU SA537 CL.1 SA537 CL.1 JAMNAGAR,
        INDIA        		 AUG.'06 ~
        JUL.'07
        8 KNPC NEW GOD
        PROJECT        		 KUWAIT NATIONAL
        PETROLEUM
        COMPANY(KUWAIT)        		 LG E&C
        (KOREA)        		 FEED/EFFLUENT
        EXCHANGER        		 6 51 1,600 9,700 AKL SA333-1 SA334-1 MINA
        KUWAIT        		 JUN. '00 ~
        APR. '01
        RECYCLE GAS/EFFLUENT
        EXCHANGER        		 1 36 1,400 6,900 AKL SA333-1 SA334-1 MINA
        KUWAIT        		 JUN. '00 ~
        APR. '01
        9 NAPHTHA REGION
        OLEFINS COMPLEX
        PROJECT        		 BASF / FINA (U.S.A.) ABB LUMMUS
        GLOBAL, INC.
        (U.S.A.)        		 HEAT EXCHANGER 13 384.4 2,150 10,700 AES 317SS 317SS PORT
        ARTHUR
        U.S.A.        		 OCT. '98 ~
        MAY.'99
        10 SINGAPORE
        OLEFINS PROJECT        		 EXXON CHEMICAL
        SINGAPORE PTE,
        LTD.(SINGAPORE)        		 M. W. KELLOGG
        CO. (U.S.A.)        		 HEAT EXCHANGER 26 712.1 2,830 12,740 AES SA516-60N SA179 JURONG,
        SINGAPORE        		 JUN. '98 ~
        JUN.'99
        11 BPC ACRYICS
        COMPLEX PROJECT        		 BASF PETRONAS
        CHEMICALS SDN
        BHD(MALAYSIA)        		 BECHTEL
        INTERNATIONAL
        INC. (SINGAPORE)        		 HEAT EXCHANGER 47 530.5 2,340 6,70 AJS CS CS KUANTAN,
        MALAYSIA        		 APR. '98 ~
        MAY.'99
        12 SHELL MEG CANADA
        PROJECT        		 SHELL CHEMICAL
        CANADA LTD.        		 FLUOR DANIEL
        (CANADA)        		 REACTOR FEED/
        PROD. EX        		 2 298 3,300 13,900 BGU 316SS 316SS ALBERTA,
        CANADA        		 FEB. '98 ~
        DEC.'98
        13 ACID GAS REMOVAL
        PROJECT        		 KUWAIT NATIONAL
        PETROLEUM CO.
        (KUWAIT)        		 SK ENGINEERING
        & CONSTRUCTION,
        LTD (KOREA)        		 DEA LEAN/RICH
        EXCHANGER, ETC        		 58 873.5 1,470 8,110 AES KCS KCS MINA ALAHMADI,
        KUWAIT        		 MAY. '97 ~
        APR.'98
        14 HANWHA PP/VCM/CA
        PROJECT        		 HANWHA
        CHEMICALS
        LTD. (KOREA)        		 HANWHA CO.
        CONSTRUCTION
        DIV.(KOREA)        		 HEAT EXCHANER,
        ETC        		 86 330 1,470 6,100 AES SA516-60N SA179 YEOCHON,
        KOREA        		 FEB. '96 ~
        DEC.'98
        15 POSM
        DEBOTTLENECKING
        PROJECT        		 YUKONG LIMITED RAYTHEON
        ENGINEERS
        (U.S.A)        		 DRUDE PO COLUMN
        CONDENSATE, ETC        		 13 344.5 1,325 10,914 BEU CS CS ULSAN,
        KOREA        		 JUL. '93 ~
        MAY '94
        16 BPCX PROJECT BANGKOK
        POLYETHYENE        		 MES
        (JAPAN)        		 1ST OVERHEAD
        CONDENSER, ETC        		 4 107 1,700 6,100 AES SA537 CL.1 SA537 CL.1 RAYONG,
        THAILAND        		 MAR. '92 ~
        NOV.'92

        Steam Drum

        NO PROJECT NAME OWNER ENG.
        CONSULTANT
        OR CONTRACTOR        		 DESCRIPTION Q'TY
        (UNIT)        		 TOTAL
        W'T
        (M/T)        		 DIMENSION
        (IDxTHKxLG, mm)        		 MAT'L LOCATION PERIOD REMARKS
        1 TPI ETHYLENE
        PROJECT        		 THAI PETROCHEMICAL
        INDUSTRY CO.
        (THAILAND)        		 SAMSUNG
        ENGINEERING CO.
        (KOREA)        		 STEAM DRUM 6 30.5 1,324 x 91 x 8,769 A515-70 RAYOUNG,
        THAILAND        		 MAR.'95 ~
        JAN.'96
        2 NCC-MODI. PROJECT LG PETROCHEMICAL
        CO., LTD(KOREA)        		 LG ENGINEERING CO.
        (KOREA)        		 STEAM DRUM 3 30.8 1,322 x 90 x 7,600 SA515-70 YEOCHUN,
        KOREA        		 JUL.'95 ~
        APR.'96
        3 0,000MTA
        ETHYLENE PROJECT        		 RAYONG OLEFINES
        CO.,LTD. (THAILAND)        		 TOYO ENGINEERING
        CORP. (JAPAN)        		 STEAM DRUM 1 33.4 1,414 x 93 x 6,900 SA516-70 RAYOUNG,
        THAILAND        		 SEP.'96 ~
        JUL.'97
        9 54.5 1,414 x 93 x 12,900 SA516-70 RAYOUNG,
        THAILAND        		 SEP.'96 ~
        JUL.'97

        Piping, Duct & Others

        NO PROJECT NAME OWNER ENG.
        CONSULTANT
        OR CONTRACTOR        		 DESCRIPTION Q'TY
        (UNIT)        		 TOTAL
        W'T
        (M/T)        		 DIMENSION
        (mm)        		 MATERIAL LOCATION PERIOD REMARKS
        1 AIN ARNAT 3X400MW
        CCPP PROJECT        		 SPE Spa. HYUNDAI E & C PIPING 1 65,000
        DIA. INCH        		 ND 1 " ~ 28" A672-B60, A312
        A106-B, A53-B        		 SETIF, ALGERIA JUN.'14 ~
        DEC.'15
        2 SAMCHEOK GREEN
        POWER PLANT        		 KOREA SOUTHERN
        POWER CO.,LTD.        		 HYUNDAI E & C AIR & GAS DUCT 1 4,904 MAX. 8,000 DIA. A36, SS400 SAMCHEOK,
        KOREA        		 DEC.'13 ~
        MAR.'16        		 YARD AREA
        3 SAMCHEOK GREEN
        POWER PLANT        		 KOREA SOUTHERN
        POWER CO.,LTD.        		 HYUNDAI E & C AIR & GAS DUCT 1 3,468 MAX. 3,500 DIA. A36, SS400 SAMCHEOK,
        KOREA        		 AUG.'13 ~
        SEP.'15        		 BOILER INSIDE
        4 DUCT OF
        HYUNDAI STEEL
        THE THIRD UNIT        		 HYUNDAI STEEL HYUNDAI E & C FURNACE DUCT 1 10,950 ND 500 ~ 4,400 SS400 TANGJIN, KOREA NOV.'11 ~
        OCT.'13        		 INCLUDING ERECTION
        5 PKG-1 PIPING OF
        HYUNDAI STEEL
        THE THIRD UNIT        		 HYUNDAI STEEL HYUNDAI E & C FURNACE PIPING 1 330,000
        DIA. INCH        		 ND 2 " ~ 24" SPPS 380
        /STS 304        		 TANGJIN, KOREA NOV.'11~
        JUN.'13        		 INCLUDING ERECTION
        STEEL STRUCTURE 1 1,220 VARIOUS SS400
        6 GUNJUNG
        CO-GENERATION
        POWER PLANT        		 GUNJUNG-COGEN
        (HANWHA E & C)        		 E-POWER
        ENGINEERING
        COMPANY        		 STEEL STRUCTURE 1 90 - A36 GUNSAN,
        KOREA        		 MAR.'11 ~
        JUN.'11
        BOILER PIPING 1 6,400
        DIA. INCH        		 ND 8 " ~ 12" A106-B, A106-C GUNSAN,
        KOREA        		 MAR.'11 ~
        JUN.'11
        7 SAMCHONPO #3,4
        T.P.P        		 KOREA SOUTH-EAST
        POWER CO.,LTD.        		 KOREA SOUTH-EAST
        POWER CO.,LTD.        		 POWER CO.,LTD.
        ASH TRANSFER TANK
        LINER FOR ASH
        HANDLING SYSTEM        		 1 11 6T x 8,000DIA
        x 12,600H        		 AR400 SAMCHONPO,
        KOREA        		 DEC. '08 ~
        JAN.'09        		 INCLUDING BASIC
        DESIGN
        8 YEOSU
        CO-GENERATION
        POWER PLANT
        (P-PROJECT)        		 YEOSU
        CO-GENERATION CO.        		 FOSTER WHEELER BOILER STEEL
        STRUCTURE        		 3 2,400 - A36, A572 YEOSU,
        KOREA        		 FEB.'08 ~
        APR.'08        		 INCLUDING DETAIL
        DESIGN
        BOILER PIPING 3 48,000
        DIA. INCH        		 ND 4 " ~ 14" A335 P22 & 91
        A106, A53        		 YEOSU,
        KOREA        		 FEB.'08 ~
        APR.'08        		 INCLUDING DETAIL
        DESIGN
        BOILER DUCT 3 1,500 MAX. 4,000 x 4,000 A36 YEOSU,
        KOREA        		 FEB.'08 ~
        APR.'08        		 INCLUDING DETAIL
        DESIGN

        Deaerator

        NO PROJECT NAME OWNER ENG.
        CONSULTANT
        OR CONTRACTOR        		 DESCRIPTION Q'TY
        (UNIT)        		 CAPACITY
        (TON/HR)        		 LOCATION PERIOD REMARKS
        1 YONGGWANG POWER
        PLANT UNIT #5,6        		 KOREA ELECTRIC
        POWER CORP.        		 KOREA ELECTRIC
        POWER CORP.        		 DEAERATOR 2 6,055 YONGGWANG,
        KOREA        		 1996 ~
        1997
        2 PUKCHEJU DIESEL POWER
        PLANT UNIT #2,3        		 KOREA ELECTRIC
        POWER CORP.        		 KOREA ELECTRIC
        POWER CORP.        		 DEAERATOR 2 246 CHEJU,
        KOREA        		 1996 ~
        1997
        3 PUSAN COMBINED CYCLE
        POWER PLANT        		 KOREA ELECTRIC
        POWER CORP.        		 KOREA ELECTRIC
        POWER CORP.        		 DEAERATOR 8 565 PUSAN,
        KOREA        		 1997 ~
        1998
        4 ULCHIN NUCLEAR POWER
        PLANT #5,6        		 KOREA ELECTRIC
        POWER CORP.        		 KOREA ELECTRIC
        POWER CORP.        		 DEAERATOR 2 6,055 ULCHIN,
        KOREA        		 1998 ~
        1999
        5 TAEAN POWER PLANT
        UNIT #5,6        		 KOREA ELECTRIC
        POWER CORP.        		 KOREA ELECTRIC
        POWER CORP.        		 DEAERATOR 2 1,656 TAEAN,
        KOREA        		 1999 ~
        2000
